Multi Needle Computer Quilting Machine For Apparel Textile Leather
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | YUTENG |
| Certification: | CE Certificate |
| Model Number: | YGB96-2-3 |
Payment & Shipping Terms:
| Price: | $10,000.00 - $60,000.00/sets |
|---|---|
| Packaging Details: | film packing |
| Supply Ability: | 300 Set/Sets per Year |
|
Detail Information |
|||
| Condition: | New | Max Sewing Speed: | 800r/min |
|---|---|---|---|
| Max Sewing Thickness: | 25mm | Number Of Head: | Multi Needle |
| Moving Style: | Frame Moved | Voltage: | 380V/220V |
| Power: | 5.5KW | Dimension(L*W*H): | 4900*1200*1800mm |
| Weight: | 4500kg | Warranty: | 1 Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Quilting Width: | 2450mm |
| The Number Of Needle Rows: | 2/3 | Space Between Needle Rows: | 3" |
| Space Between Needle: | 25.4mm | X-axis Movement Displacement: | 254mm |
| Stitch Length: | 2-6mm | Speed Of Operation: | 20-120m/hour |
| Model Of Needle: | 16# 19# | Port: | Shenzhen |
| Highlight: | Multi Needle Computer Quilting Machine,Apparel Computer Quilting Machine,Leather Multi Needle Quilting Machine |
||
Product Description
Computer Controling Apparel And Textile Multi Needle Quilting Machine
PURPOSE:
It is widely used for quilting high-quality garments, bedding covers, textile, leather, shoes, cap, bags,vanity, gloves,sleeping bag, seat cover and wall decoration etc.
Product Main Features:
- Computerized speed governing, Max.800r/min.
- Needle row driven by aluminum alloy needle bar frame structure. Oil free, sturdy and durable.
- Saddles and Rollers driven by Servo drive equipment,Spindle adopts frequency conversion control.
- Saddles using quilting machine with high rigidity design. The stand of fabric seprate from saddles, effectively reduce the operaing load of motor.
- Dual clutch device, to solve the synchronization problem of rollers in front and back.
- Using high-pricision and high rigidity imported screw mandrel.
- 360 degree free quilting come with unlimited Multi-span quilting independent patterns.
- Automatic thread-break detection unit.
- Infrared sensor make sure more safety operation.
- The machine runs smoothly, low noise, high precision, low thread-break rate and easy to operate
| Model | Size | Quilting speed | Speed of operation | Thickness of quilting | Quilting width |
| YGB64-2-3 | 4900*1200*1800MM | 300-800R/MIN | 20-120M/HOUR | <=25MM | 2450mm |
| Other Specification |
The number of needle rows: 2/3 Space between needle rows: 3" Space between needle: 25.4mm X-axis movement displacement: 254mm Stitch length: 2-6mm Model of needle: 16# 19# Voltage: 380V/220V Total power: 5.5KW Gross weight: 4500kg |
||||
Related products
Packaging & Shipping
NOTE:
1. Delivery Time: It is generally within 7 to 30 days upon receipt of your 30% deposit, but it depends on the final quantity of the order.
2.The normal packing is PE film packing , if customer ask wooden box is both ok, and the wooden box will be fumigated.
3.Sea port: shenzhen
4. Payment Terms: T/T 30% deposit in advance, 70% balance before shipment.
5. Delivery Terms: FOB, CIF, CFR, etc.
